KDM Low-speed pneumatic drill machine

The KRAIS KDM is a high-torque, pneumatic, low-speed drilling machine for a wide range of tube work applications. The KDM pneumatic drill can be used as a portable drive for many common service tasks and, when combined with the proper tools, supports versatile work on tubes and related components.

Applications

  • Tube sheet drilling and reaming during heat exchanger maintenance in oil refineries
  • Condenser tube service and repair in thermal power plants
  • Finfan cooler tube bundle maintenance in petrochemical plants

KDM Series (4 tools)

modelFree speedTorquePowerAir useTool weigthAdd to quote
ImperialMetricImperialMetricImperialMetricImperialMetric
70-KDM70138.7 ft.lbs188 Nm1.61 hp1200 W42.38 CFM1200 L/min14.33 lbs6,5 kgTool and partsGo for quote
130-KDM13077.4 ft.lbs105 Nm1.61 hp1200 W42.38 CFM1200 L/min14.33 lbs6,5 kgTool and partsGo for quote
180-KDM18058.3 ft.lbs79 Nm1.61 hp1200 W42.38 CFM1200 L/min14.33 lbs6,5 kgTool and partsGo for quote
400-KDM40026.6 ft.lbs36 Nm1.61 hp1200 W42.38 CFM1200 L/min14.33 lbs6,5 kgTool and partsGo for quote
