KS Basic Boiler Tube Expanders

Three expansion rolls with three flare rolls, self feeding boiler expanders. Expanders simultaneously expand and flare the tube.

KS Series (108 tools)

TOOL NO.	Tube OD		Tube Gauge [BWG]	Expansion range		Roll lenght	Mandrel length	Short mandrel length	Mandrel square	Add to quote
TOOL NO.	Imperial	Metric	Tube Gauge [BWG]	Imperial	Metric	Roll lenght	Mandrel length	Short mandrel length	Mandrel square	Add to quote
KS-1942	1” in	25,40 mm	9-11	0.748 - 0.866 in	19,0 - 22,0 mm	42 mm	196 mm	-	1/2	Tool and partsGo for quote
KS-2042	1” in	25,40 mm	13-14	0.787 - 0.906 in	20,0 - 23,0 mm	42 mm	196 mm	-	1/2	Tool and partsGo for quote
KS-2242	1-1/4” in	31,75 mm	7	0.866 - 0.984 in	22,0 - 25,0 mm	42 mm	196 mm	-	1/2	Tool and partsGo for quote
KS-2342	1-1/4” in	31,75 mm	9	0.906 - 1.024 in	23,0 - 26,0 mm	42 mm	196 mm	-	1/2	Tool and partsGo for quote
KS-2442	1-1/4” in	31,75 mm	10	0.945 - 1.063 in	24,0 - 27,0 mm	42 mm	196 mm	-	1/2	Tool and partsGo for quote
KS-2542	1-1/4” in	31,75 mm	11-13	0.984 - 1.102 in	25,0 - 28,0 mm	42 mm	196 mm	-	1/2	Tool and partsGo for quote
KS-2642	1-1/4” in	31,75 mm	12-14	1.024 - 1.142 in	26,0 - 29,0 mm	42 mm	196 mm	-	1/2	Tool and partsGo for quote
KS-2742	1-1/4” in	31,75 mm	14-15	1.063 - 1.181 in	27,0 - 30,0 mm	42 mm	196 mm	-	1/2	Tool and partsGo for quote
KS-2842	1-1/4” in	31,75 mm	16	1.102 - 1.260 in	28,0 - 32,0 mm	42 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-2850	1-1/4” in	31,75 mm	16	1.102 - 1.260 in	28,0 - 32,0 mm	50 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-2860	1-1/4” in	31,75 mm	16	1.102 - 1.260 in	28,0 - 32,0 mm	60 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-2880	1-1/4” in	31,75 mm	16	1.102 - 1.260 in	28,0 - 32,0 mm	80 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-2942	1-1/2” in	38,10 mm	7-10	1.142 - 1.299 in	29,0 - 33,0 mm	42 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-2950	1-1/2” in	38,10 mm	7-10	1.142 - 1.299 in	29,0 - 33,0 mm	50 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-2960	1-1/2” in	38,10 mm	7-10	1.142 - 1.299 in	29,0 - 33,0 mm	60 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-2980	1-1/2” in	38,10 mm	7-10	1.142 - 1.299 in	29,0 - 33,0 mm	80 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3042	1-1/2” in	38,10 mm	10-12	1.181 - 1.339 in	30,0 - 34,0 mm	42 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3050	1-1/2” in	38,10 mm	10-12	1.181 - 1.339 in	30,0 - 34,0 mm	50 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3060	1-1/2” in	38,10 mm	10-12	1.181 - 1.339 in	30,0 - 34,0 mm	60 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3080	1-1/2” in	38,10 mm	10-12	1.181 - 1.339 in	30,0 - 34,0 mm	80 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3242	1-1/2” in	38,10 mm	12-14	1.260 - 1.417 in	32,0 - 36,0 mm	42 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3250	1-1/2” in	38,10 mm	12-14	1.260 - 1.417 in	32,0 - 36,0 mm	50 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3260	1-1/2” in	38,10 mm	12-14	1.260 - 1.417 in	32,0 - 36,0 mm	60 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3280	1-1/2” in	38,10 mm	12-14	1.260 - 1.417 in	32,0 - 36,0 mm	80 mm	260 mm	175	3/4	Tool and partsGo for quote
KS-3342	1-1/2” in	38,10 mm	13-20	1.299 - 1.496 in	33,0 - 38,0 mm	42 mm	290 mm	181	3/4	Tool and partsGo for quote
KS-3350	1-1/2” in	38,10 mm	13-20	1.299 - 1.496 in	33,0 - 38,0 mm	50 mm	290 mm	181	3/4	Tool and partsGo for quote
KS-3360	1-1/2” in	38,10 mm	13-20	1.299 - 1.496 in	33,0 - 38,0 mm	60 mm	290 mm	181	3/4	Tool and partsGo for quote
KS-3380	1-1/2” in	38,10 mm	13-20	1.299 - 1.496 in	33,0 - 38,0 mm	80 mm	290 mm	181	3/4	Tool and partsGo for quote
KS-3542	1-3/4” in	44,45 mm	8-9	1.378 - 1.614 in	35,0 - 41,0 mm	42 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3550	1-3/4” in	44,45 mm	8-9	1.378 - 1.614 in	35,0 - 41,0 mm	50 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3560	1-3/4” in	44,45 mm	8-9	1.378 - 1.614 in	35,0 - 41,0 mm	60 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3580	1-3/4” in	44,45 mm	8-9	1.378 - 1.614 in	35,0 - 41,0 mm	80 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3742	1-3/4” in	44,45 mm	10-12	1.457 - 1.693 in	37,0 - 43,0 mm	42 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3750	1-3/4” in	44,45 mm	10-12	1.457 - 1.693 in	37,0 - 43,0 mm	50 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3760	1-3/4” in	44,45 mm	10-12	1.457 - 1.693 in	37,0 - 43,0 mm	60 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3780	1-3/4” in	44,45 mm	10-12	1.457 - 1.693 in	37,0 - 43,0 mm	80 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3942	1-3/4” in	44,45 mm	12-18	1.535 - 1.772 in	39,0 - 45,0 mm	42 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3950	1-3/4” in	44,45 mm	12-18	1.535 - 1.772 in	39,0 - 45,0 mm	50 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3960	1-3/4” in	44,45 mm	12-18	1.535 - 1.772 in	39,0 - 45,0 mm	60 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-3980	1-3/4” in	44,45 mm	12-18	1.535 - 1.772 in	39,0 - 45,0 mm	80 mm	310 mm	188	3/4	Tool and partsGo for quote
KS-4040	2” in	50,80 mm	7-9	1.575 - 1.811 in	40,0 - 46,0 mm	40 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4050	2” in	50,80 mm	7-9	1.575 - 1.811 in	40,0 - 46,0 mm	50 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4060	2” in	50,80 mm	7-9	1.575 - 1.811 in	40,0 - 46,0 mm	60 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4080	2” in	50,80 mm	7-9	1.575 - 1.811 in	40,0 - 46,0 mm	80 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4240	2” in	50,80 mm	10-13	1.654 - 1.890 in	42,0 - 48,0 mm	40 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4250	2” in	50,80 mm	10-13	1.654 - 1.890 in	42,0 - 48,0 mm	50 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4260	2” in	50,80 mm	10-13	1.654 - 1.890 in	42,0 - 48,0 mm	60 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4280	2” in	50,80 mm	10-13	1.654 - 1.890 in	42,0 - 48,0 mm	80 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4440	2” in	50,80 mm	12-14	1.732 - 1.969 in	44,0 - 50,0 mm	40 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4450	2” in	50,80 mm	12-14	1.732 - 1.969 in	44,0 - 50,0 mm	50 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4460	2” in	50,80 mm	12-14	1.732 - 1.969 in	44,0 - 50,0 mm	60 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4480	2” in	50,80 mm	12-14	1.732 - 1.969 in	44,0 - 50,0 mm	80 mm	310 mm	205	3/4	Tool and partsGo for quote
KS-4740	2” in	50,80 mm	15-16	1.850 - 2.126 in	47,0 - 54,0 mm	40 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-4750	2” in	50,80 mm	15-16	1.850 - 2.126 in	47,0 - 54,0 mm	50 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-4760	2” in	50,80 mm	15-16	1.850 - 2.126 in	47,0 - 54,0 mm	60 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-4780	2” in	50,80 mm	15-16	1.850 - 2.126 in	47,0 - 54,0 mm	80 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-4940	2-1/4” in	57,15 mm	10-13	1.929 - 2.205 in	49,0 - 56,0 mm	40 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-4950	2-1/4” in	57,15 mm	10-13	1.929 - 2.205 in	49,0 - 56,0 mm	50 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-4960	2-1/4” in	57,15 mm	10-13	1.929 - 2.205 in	49,0 - 56,0 mm	60 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-4980	2-1/4” in	57,15 mm	10-13	1.929 - 2.205 in	49,0 - 56,0 mm	80 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-5240	2-1/4” in	57,15 mm	14-16	2.047 - 2.323 in	52,0 - 59,0 mm	40 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-5250	2-1/4” in	57,15 mm	14-16	2.047 - 2.323 in	52,0 - 59,0 mm	50 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-5260	2-1/4” in	57,15 mm	14-16	2.047 - 2.323 in	52,0 - 59,0 mm	60 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-5280	2-1/4” in	57,15 mm	14-16	2.047 - 2.323 in	52,0 - 59,0 mm	80 mm	340 mm	218	3/4	Tool and partsGo for quote
KS-5440	2-1/2” in	63,50 mm	8-13	2.126 - 2.441 in	54,0 - 62,0 mm	40 mm	375 mm	230	3/4	Tool and partsGo for quote
KS-5450	2-1/2” in	63,50 mm	8-13	2.126 - 2.441 in	54,0 - 62,0 mm	50 mm	375 mm	230	3/4	Tool and partsGo for quote
KS-5460	2-1/2” in	63,50 mm	8-13	2.126 - 2.441 in	54,0 - 62,0 mm	60 mm	375 mm	230	3/4	Tool and partsGo for quote
KS-5480	2-1/2” in	63,50 mm	8-13	2.126 - 2.441 in	54,0 - 62,0 mm	80 mm	375 mm	230	3/4	Tool and partsGo for quote
KS-5740	2-1/2” in	63,50 mm	12-16	2.244 - 2.598 in	57,0 - 66,0 mm	40 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-5750	2-1/2” in	63,50 mm	12-16	2.244 - 2.598 in	57,0 - 66,0 mm	50 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-5760	2-1/2” in	63,50 mm	12-16	2.244 - 2.598 in	57,0 - 66,0 mm	60 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-5780	2-1/2” in	63,50 mm	12-16	2.244 - 2.598 in	57,0 - 66,0 mm	80 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6040	2-3/4” in	69,85 mm	7-11	2.362 - 2.717 in	60,0 - 69,0 mm	40 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6050	2-3/4” in	69,85 mm	7-11	2.362 - 2.717 in	60,0 - 69,0 mm	50 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6060	2-3/4” in	69,85 mm	7-11	2.362 - 2.717 in	60,0 - 69,0 mm	60 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6080	2-3/4” in	69,85 mm	7-11	2.362 - 2.717 in	60,0 - 69,0 mm	80 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6540	3” in	76,20 mm	7-8	2.559 - 2.913 in	65,0 - 74,0 mm	40 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6550	3” in	76,20 mm	7-8	2.559 - 2.913 in	65,0 - 74,0 mm	50 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6560	3” in	76,20 mm	7-8	2.559 - 2.913 in	65,0 - 74,0 mm	60 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6580	3” in	76,20 mm	7-8	2.559 - 2.913 in	65,0 - 74,0 mm	80 mm	395 mm	235	3/4	Tool and partsGo for quote
KS-6840	3” in	76,20 mm	10-14	2.677 - 3.031 in	68,0 - 77,0 mm	40 mm	403 mm	255	1	Tool and partsGo for quote
KS-6850	3” in	76,20 mm	10-14	2.677 - 3.031 in	68,0 - 77,0 mm	50 mm	403 mm	255	1	Tool and partsGo for quote
KS-6860	3” in	76,20 mm	10-14	2.677 - 3.031 in	68,0 - 77,0 mm	60 mm	403 mm	255	1	Tool and partsGo for quote
KS-6880	3” in	76,20 mm	10-14	2.677 - 3.031 in	68,0 - 77,0 mm	80 mm	403 mm	255	1	Tool and partsGo for quote
KS-7240	3-1/4” in	82,55 mm	7-11	2.835 - 3.189 in	72,0 - 81,0 mm	40 mm	403 mm	255	1	Tool and partsGo for quote
KS-7250	3-1/4” in	82,55 mm	7-11	2.835 - 3.189 in	72,0 - 81,0 mm	50 mm	403 mm	255	1	Tool and partsGo for quote
KS-7260	3-1/4” in	82,55 mm	7-11	2.835 - 3.189 in	72,0 - 81,0 mm	60 mm	403 mm	255	1	Tool and partsGo for quote
KS-7280	3-1/4” in	82,55 mm	7-11	2.835 - 3.189 in	72,0 - 81,0 mm	80 mm	403 mm	255	1	Tool and partsGo for quote
KS-7740	3-1/4” in	82,55 mm	15-16	3.031 - 3.425 in	77,0 - 87,0 mm	40 mm	422 mm	255	1	Tool and partsGo for quote
KS-7750	3-1/4” in	82,55 mm	15-16	3.031 - 3.425 in	77,0 - 87,0 mm	50 mm	422 mm	255	1	Tool and partsGo for quote
KS-7760	3-1/4” in	82,55 mm	15-16	3.031 - 3.425 in	77,0 - 87,0 mm	60 mm	422 mm	255	1	Tool and partsGo for quote
KS-7780	3-1/4” in	82,55 mm	15-16	3.031 - 3.425 in	77,0 - 87,0 mm	80 mm	422 mm	255	1	Tool and partsGo for quote
KS-8240	3-1/2” in	88,90 mm	10-13	3.228 - 3.622 in	82,0 - 92,0 mm	40 mm	422 mm	255	1	Tool and partsGo for quote
KS-8250	3-1/2” in	88,90 mm	10-13	3.228 - 3.622 in	82,0 - 92,0 mm	50 mm	422 mm	255	1	Tool and partsGo for quote
KS-8260	3-1/2” in	88,90 mm	10-13	3.228 - 3.622 in	82,0 - 92,0 mm	60 mm	422 mm	255	1	Tool and partsGo for quote
KS-8280	3-1/2” in	88,90 mm	10-13	3.228 - 3.622 in	82,0 - 92,0 mm	80 mm	422 mm	255	1	Tool and partsGo for quote
KS-8640	3-3/4” in	95,25 mm	8-12	3.386 - 3.780 in	86,0 - 96,0 mm	40 mm	422 mm	255	1	Tool and partsGo for quote
KS-8650	3-3/4” in	95,25 mm	8-12	3.386 - 3.780 in	86,0 - 96,0 mm	50 mm	422 mm	255	1	Tool and partsGo for quote
KS-8660	3-3/4” in	95,25 mm	8-12	3.386 - 3.780 in	86,0 - 96,0 mm	60 mm	422 mm	255	1	Tool and partsGo for quote
KS-8680	3-3/4” in	95,25 mm	8-12	3.386 - 3.780 in	86,0 - 96,0 mm	80 mm	422 mm	255	1	Tool and partsGo for quote
KS-9040	4” in	101,60 mm	9-12	3.543 - 3.937 in	90,0 - 100,0 mm	40 mm	422 mm	275	1	Tool and partsGo for quote
KS-9050	4” in	101,60 mm	9-12	3.543 - 3.937 in	90,0 - 100,0 mm	50 mm	422 mm	275	1	Tool and partsGo for quote
KS-9060	4” in	101,60 mm	9-12	3.543 - 3.937 in	90,0 - 100,0 mm	60 mm	422 mm	275	1	Tool and partsGo for quote
KS-9080	4” in	101,60 mm	9-12	3.543 - 3.937 in	90,0 - 100,0 mm	80 mm	422 mm	275	1	Tool and partsGo for quote
KS-9640	4” in	101,60 mm	16	3.780 - 4.173 in	96,0 - 106,0 mm	40 mm	422 mm	275	1	Tool and partsGo for quote
KS-9650	4” in	101,60 mm	16	3.780 - 4.173 in	96,0 - 106,0 mm	50 mm	422 mm	275	1	Tool and partsGo for quote
KS-9660	4” in	101,60 mm	16	3.780 - 4.173 in	96,0 - 106,0 mm	60 mm	422 mm	275	1	Tool and partsGo for quote
KS-9680	4” in	101,60 mm	16	3.780 - 4.173 in	96,0 - 106,0 mm	80 mm	422 mm	275	1	Tool and partsGo for quote

KS Basic Boiler Tube Expanders
